Hybrid Inverter 5-13kW Three-Phase
-
Small In Size, Big On Power.
Features
Powerful
Max. 18A DC input current per string, compatible with 182/210 PV modules.
Ultra-wide MPPT voltage range captures every ray of light from dawn to dusk, maximizing energy collection.
Flexible
Up to 110% three-phase unbalanced output, increasing self-use ratio and optimizing solar production.
Max. of 5 units in parallel, offering a cost-effective commercial solution.
Effective
High charge/discharge efficiency, up to 98.5%/97.7%.
Reduced energy loss between battery and inverter interaction.
Friendly
<25dB, no noise pollution.
IP65, indoor or outdoor application.
Technical Specifications
WH-THA502
Max DC Input Power
7500W
NO. of MPP Trackers
2
NO. of Strings Per MPP Trackers
1
Max. Apparent Power to Grid
5000W
Maximum Output Current
8.1A
Maximum Current
16.2A
Battery Voltage Range
160~700V
Dimensions (W*D*H)
510*205*480mm
Operation Temperature
-25°C to 60°C
Ingress Protection
IP65
Noise Emission
<25dB
As a hybrid solar inverter supplier, hybrid solar inverter factory, we can provide kinds of hybrid solar inverter for sale, and the 3 phase hybrid inverter price is reasonable. If you want to buy 3 phase hybrid inverter , please contact us.
If you want to know more kinds of hybrid solar inverter china , please visit our website.
WHES is a world-leading supplier of battery storage systems for homes, offering solutions for a full range of customer segments, including utility, commercial & industrial, and residential. Our sales network spans across Asia, Europe, Australia, and the Middle East. With three manufacturing and design centers in China, we currently have a 2.5 GWh capacity, which is expanding.
