Steel Wire Rope Slings Manufacturer And Supplier In China

• Posted by kin ryo November 7, 2024 Filed in Business #Steel Wire Rope Slings Manufacturer And Supplier In China  #Wire Rope Slings  #Steel Wire Rope Slings  #Wire Rope Slings Manufacturer  #Manufacturer And Supplier In China  27 views
  click to rate

  Introduction to the wire rope slings industry:

  Steel wire rope slings manufacturer, our wire rope manufacturing plant established in 1997. The production area covers an area of more than 20,000 square metres. Under the jurisdiction of large-scale wire rope rigging manufacturing plant and small-scale wire rope rigging manufacturing plant two sub-factories. Annual production capacity of 30,000 tonnes, with all kinds of professional and technical personnel more than 160 people, including 10 engineers. The products of wire rope rigging mainly include complete sets of lifting rigging, space structure pulling ropes, bridge building slings and ocean marine large-sized rope coil cables, and the rigging includes pressed rigging, plug braided rigging, casting rigging, jointless rope coil, plug braided cable and special rigging according to the types, and the production range of the products is from 6mm to 570mm in diameter.



  Small Wire Rope Rigging Manufacturing Plant：

  Small wire rope rigging manufacturing plant covering an area of 6,000 square metres. Scope of production: plaiting rigging and pressing rigging up to 20mm, and unspliced rope loops up to 60mm. There are 61 production staff.



  Large Wire Rope Slings Manufacturer：

  The large wire rope rigging manufacturing plant covers an area of 15,360 square metres. Scope of production: Plug braided rigging, pressed rigging and casting rigging over 20mm, spliceless coils over 60mm, plug braided steel cables and special rigging. There are 80 production staff.



  Pressed wire rope rigging：

  Pressing lifting slings divide into common type aluminium tube pressing rigging and steel rigging. And the common type aluminium tube pressing rigging include pressing rope sleeve and multi-leg pressing complete rigging. Besides, steel rigging dividing into common steel and stainless steel according to the material of anchorage. According to the type of steel wire rope, including common steel wire rope and single-stranded steel wire rope. In other aspect, according to the type of adjustment, it has fixed type and adjustable type.







  Plug-in wire rope slings：

  Braided rigging includes both braided rope sets and multi-legged braided sets.





  Cast wire rope slings：

  According to the casting method, include hot casting and cold casting two types. According to the form of anchorage: open type, closed type, fork ear type, single ear type. And each other after the combination of the formation of a variety of adjustable casting rigging. The solidification rate of casting rigging is 100%.







  Spliceless Rope Loop：

  Spliceless rope loops come into two types: normal type and high performance type. There is a red mark on the outside of the rope loop (no-hanging point). And it strictly prohibit to use the ‘no-hanging point’ as the point of hoisting or the point under hoist during the hoisting operation.



  Plugged and braided steel cables：





  Special wire rope slings：

  The special wire rope slings are shaped slings made at the request of customers under the conditions of limited lifting space and special requirements.



  Wire rope sling production equipment：

  Wire Rope Rigging Manufacturing General Factory has self-developed Φ100, Φ200, Φ400 rope coil winding machines; steel cable insertion sleeve machine, ordinary insertion sleeve machine and press sleeve machine and 10,000 tonnes of presses; hot and cold casting rigging production line, specialised storage and discharging logistics production line, and is equipped with 300 tonnes (70m) and 2500 tonnes tensile testing machine (80m).





  Steel Wire Rope Sleeving Machine：

  Wire Rope Pressing Sleeve Machine is a special equipment for deep processing of wire rope and metal cemented tube by using the characteristic of plastic deformation of metal raw material by extrusion. It is characterised by high cementation strength, large safety load, advanced technology and high efficiency. Our company has 300t, 500t, 1000t, 2000t, 3000t, 10000t press sleeve machine group, the maximum pressing diameter of 190mm.





  Steel Cable insertion and braiding machine：

  Cable inserting and braiding machine is divided into vertical and horizontal two kinds, horizontal cable inserting and braiding machine consists of rotating system, mechanical positioning system, etc., through the retwisting and rotating can be achieved by large-scale steel cable products processing and production, convenient and quick, the maximum production capacity of φ500; vertical cable inserting and braiding machine consists of a rotating platform, hydraulic positioning system, etc., through the hydraulic manipulator can be achieved by the processing of the production of steel cable products, flexible and convenient, the maximum production capacity φ It is flexible and convenient, with a maximum production capacity of φ400.





  Spliceless Rope Coil Winding Equipment：

  Jointless Rope Loop Winding Equipment is one of the equipments with independent intellectual property rights in our factory. We have 100mm, 200mm and 400mm rope loop machines, especially the 400mm rope loop machine consists of full-automatic take-up and pay-off system, rotary de-twisting system, hydraulic tensioning system, PLC human nature operation platform, etc. Its production capacity is the first one in Asia, and it is one of the invention and patented products of our company as well.



  Wire Rope Slings Product Applications:

  The products are widely used in bridge construction, port machinery, marine engineering, wind power military, oil drilling and daily lifting, professional service has been praised by users.









  Why choose wire rope slings from Hebei Connect Trading Co., Ltd.？

  Choosing our steel wire rope slings is undoubtedly the best decision you can make. We pride ourselves on delivering top-notch quality that meets the highest industry standards. Our steel wire rope slings are designed for durability and reliability, ensuring that your lifting operations are safe and efficient. Trust us for unparalleled strength and performance in every sling we produce.



  Custom Wire Rope Sling Manufacturer



  1. Complete Steel Wire Rope Sling Products:  A wire rope sling manufacturer supplies comprehensive type of wire rope slings, Special custom designing to meet variour heavy-duty lifting and hoisting applications.Thimble Wire Rope Sling. Grommet Wire Rope Sling. Spliced Eye Rope Sling. Pressed Steel Cable Sling. Single Leg to Multi Leg Wire Rope Slings. Custom Steel…
